The vertical thread rolling machine is characterized by its upright structural layout, where feeding, rolling, and discharge are arranged along a vertical axis. This design helps create a clear operating sequence and allows operators to observe the rolling process from a direct working angle.
Vertical threading machine is a non-standard semi-automatic threader, suitable for all kinds of headless bolt threading and long rod threading.Solutions presented through TAICHUANG are evaluated according to drawings and application requirements to ensure proper configuration selection.
|
Model |
Max.Blank Diameter/mm |
Max.Blank Length/mm |
Moving Dies Stationary Length/mm |
Capacity/pcs/min |
Main Motor Power/kw |
Volume(L*W*H)/m |
Weight/kg |
|
|
R4-40 |
M4 |
40 |
89*25*40 |
76*25*40 |
80-120 |
Level6-2.2kw |
1.30*1.00*1.40 |
800 |
|
R5-65 |
M5 |
65 |
105*25*65 |
90*25*65 |
80-100 |
Level 4-3kw |
1.30*1.00*1.40 |
1000 |
|
R6-80 |
M6 |
80 |
125*25*80 |
110*25*80 |
70-90 |
Level 4-4kw |
1.50*1.00*1.55 |
1100 |
|
R6-120 |
M6 |
120 |
125*25*120 |
110*25*120 |
70-80 |
Level 4-4kw |
1.50*1.00*1.55 |
1200 |
|
R8-80 |
M8 |
80 |
140*30*80 |
125*30*80 |
60-70 |
Level 6-5.5kw |
1.50*1.00*1.70 |
1500 |
|
R8-130 |
M8 |
130 |
140*30*130 |
125*30*130 |
60-70 |
Level 6-7.5kw |
1.50*1.00*1.70 |
1650 |
|
R10-100 |
M10 |
100 |
170*30*100 |
150*30*100 |
55-60 |
Level 6-7.5kw |
2.15*1.25*1.70 |
1950 |
|
R12-120 |
M12 |
120 |
210*40*120 |
190*40*120 |
50-55 |
Level 6-11kw |
2.25*1.50*2.29 |
2800 |
Thread forming is achieved through controlled cold deformation, allowing the material’s fiber structure to remain intact. This Vertical Thread Rolling Machine emphasizes repeatable rolling results and consistent thread geometry based on confirmed rolling parameters.
Rather than focusing on frequent adjustment, the process is configured according to actual fastener drawings and material characteristics. This approach supports predictable rolling behavior and helps maintain stable output quality during regular operation schedules.
Rather than offering generic recommendations, TAICHUANG emphasizes requirement clarification and technical communication. Buyers are supported through fastener drawing review, process discussion, and configuration confirmation to help ensure the selected thread rolling machine matches real production needs. This sourcing approach helps reduce mismatches and improves procurement efficiency.
Q1: What is the main difference between vertical and horizontal thread rolling machines?
Vertical machines use an upright structural layout, offering a different feeding and observation perspective compared with horizontal designs.
Q2: Does the vertical structure affect rolling accuracy?
Rolling accuracy depends on die alignment and process configuration rather than machine orientation.
Q3: Is this thread rolling machine suitable for different fastener materials?
Suitability is evaluated based on confirmed drawings, material characteristics, and thread requirements.
