At TAICHUANG, we always place great emphasis on control accuracy and production stability when designing PLC nut tapping machines. By combining robust mechanical structures with intelligent control systems, we offer a solution that helps manufacturers achieve consistent thread quality and efficient production processes.
Our PLC-based control system can fully control key parameters such as tapping speed, depth, cycle time, and spindle operation. This refined control capability ensures that each tapping cycle is executed under optimal working conditions, thereby effectively reducing machining errors and improving the overall quality of the product.
Compared to traditional machine tools, our solution offers a more standardized and programmable operational workflow. Once the parameters are configured, the equipment can operate continuously with minimal human intervention, making it ideally suited for large-scale production environments.
As a manufacturer, we fully understand that long-term equipment reliability is just as critical as performance. For this reason, our machines are constructed using high-quality components and undergo rigorous, comprehensive testing prior to leaving our facility. Our goal is to ensure that the equipment remains stable during long-term operation, thereby reducing maintenance frequency and further improving production efficiency.
For customers seeking to purchase PLC nut tapping machines from reliable suppliers, TAICHUANG offers a comprehensive solution that combines intelligent control, robust construction, and highly competitive pricing.
|
Item |
Name |
Parameter |
Name |
Parameters/Brand |
|
|
Casting base |
Pallet stroke |
0-270mm |
Main spindle servo motor |
2.5Kw/3000rpm |
M5-M8 Air pressure clamping |
|
Main spindle slide stroke |
0-65mm |
Feed servo motor |
0.4Kw/3000rpm |
||
|
Number of main spindles |
2 |
Main spindle servo motor |
2.9Kw/1500rpm |
M8-M12 Hydraulic clamping |
|
|
Feed ball screw |
SFAR2010X234 |
Feed servo motor |
0.75Kw/3000rps |
||
|
Cutting track |
Cutting angle |
30 degree angle |
Touch screen |
Inovance/Siemens |
|
|
Fixture mode |
Turntable fixture |
Max.diameter of turntable:∅146 |
Main engine |
Inovance/Siemens |
|
|
Feeding cylinder |
Cylinder |
Airtac MA32X75SCA |
Circuit-breaker |
CHNT |
|
|
Clamping cylinder |
Cylinder |
Airtac SDA50X30SB |
Contactor |
CHNT |
|
|
Oil cylinder |
D32X25SB |
Thermal overload |
CHNT |
||
|
Board |
Productivity per spindle |
20-60 pcs/min |
KA |
CHNT |
|
|
Cooling pump motor |
Power:370w-flow:120L/min |
Power switch |
IDCE |
||
|
Hydraulic unit motor |
Power:0.75KW-displacementVP15 |
Origin sensor |
OMRON |
||
|
Overall Dimensions |
2400×1600×1950mm |
Cylinder sensor |
Airtac |
||
Our PLC nut tapping machines have a wide range of applications, serving many industries with extremely high requirements for automation, processing performance stability, and standardized mass production. With its intelligent PLC core control system, this equipment boasts significant advantages such as ease of operation, stable performance, and strong compatibility, perfectly meeting the increasingly diverse processing needs of modern fastener factories.
Key Applicable Industries and Production Sectors:
Automotive Fastener Manufacturing
Architectural Hardware and Construction Fastener Manufacturing
Precision Component Processing for Electrical, Electronic, and Home Appliance Industries
General Industrial Machinery and Mechanical Parts Processing
In addition to functioning as a standalone unit, our "TAICHUANG" brand nut tapping machine facilitates seamless integration and synchronized operation with upstream and downstream equipment. It can be seamlessly integrated into a fully automated production line to achieve continuous operation of the entire process, including automatic feeding, tapping, screening, and unloading. This highly automated production model significantly minimizes manual intervention, optimizes the overall manufacturing process, and empowers clients to achieve their long-term production goals of high volume, low cost, and high efficiency.
Whether for mass production, customized processing, or mixed production needs, our tapping equipment can provide manufacturers worldwide with stable product quality and higher production efficiency.
Yes, this equipment is designed specifically for continuous industrial production.
The equipment configuration can be customized to meet specific requirements.
We provide sample testing support.
Customer Benefits:
Improved production stability
Reduced human error
Increased production efficiency
Common Buyer Concerns:
How to choose the right PLC equipment?
The selection depends on the specific production requirements and nut specifications.
Why choose TAICHUANG?
Reliable quality, intelligent control capabilities, and professional technical support.
